Solderweld SW-ALCU5K Al-Cop Braze Aluminum to Copper Brazing Rod

Al-Cop Braze is used to join aluminum and copper. It has a low melting point and narrow melt range; suitable for brazing aluminum alloys. High zinc content relative to other aluminum filler metals provides increased wetability.

Specifications:

• Quantity per pack: 5 Ea


• Package Weight: 0.13 lbs.


• Rod Length: 18 inches


• Packaging: 18.5x.09 dia plastic tube


• Shelf Life: 2 years at ambient temp.


• Density (Lbs/in): 0.19


• Recommended Brazing Temp.: 950-1000F (510-537C)


• Liquidus: 905F (471C)


• Solidus: 826F (441C)


• Appearance: Silver-Colored with White Flux Channel

Features/Benefits

• Solution temperature during heat treating must be below the solidus of the braze alloy in order to ensure integrity of the joint is maintained.


• Joining all brazeable grades of aluminum and copper; Aluminum to Aluminum or Aluminum to Copper wire pigtail splices; Aluminum to Copper, Aluminum to Brass or plated terminals


• Where it is desirable to attain flow into tight capillary joints


• HVAC applications with Brass, Copper, Aluminum and Steel


• Is effective with any of these heat sources: Oxy-acetylene torch, Natural gas torch, MAPP Gas, Induction

Can Replace Harris AluxCor 78-22
